在开发Windows桌面应用程序时，我们经常需要在自己的应用程序中嵌入并控制其他可执行程序。本文将详细介绍如何在C# WinForms应用程序中实现这一功能，并提供多个实用示例。
基本概念 嵌入外部程序意味着将其他Windows应用程序的窗口作为子窗口嵌入到我们的WinForms应用程序中。这种技术通常用于：
集成第三方工具 创建复合应用程序 提供统一的用户界面 控制和管理多个应用程序 技术实现 基本实现类 创建一个专门用于管理嵌入程序的类：
using System; using System.Collections.Generic; using System.Diagnostics; using System.Linq; using System.Runtime.InteropServices; using System.Text; using System.Threading.Tasks; namespace AppEmbedding { public class ExternalProcessManager { // Windows API 常量 private const int GWL_STYLE = -16 ; private const int WS_CHILD = 0x40000000 ; private const int WS_VISIBLE = 0x10000000 ; // Windows API 声明 private static class WindowsAPI { [DllImport( "user32.dll" )] public static extern IntPtr SetParent (IntPtr hWndChild, IntPtr hWndNewParent) ; [DllImport( "user32.dll" )] public static extern int GetWindowLong (IntPtr hWnd, int nIndex) ; [DllImport( "user32.dll" )] public static extern int SetWindowLong (IntPtr hWnd, int nIndex, int dwNewLong) ; [DllImport( "user32.dll" )] public static extern bool ShowWindow (IntPtr hWnd, int nCmdShow) ; [DllImport( "user32.dll" )] public static extern bool MoveWindow (IntPtr hWnd, int X, int Y, int nWidth, int nHeight, bool bRepaint) ; } private Process _embeddedProcess; private Control _parentControl; public ExternalProcessManager (Control parentControl) { _parentControl = parentControl; } public void EmbedProcess ( string processPath) { try { // 启动进程 - 使用 UseShellExecute = false 可能对某些应用程序更有效 ProcessStartInfo startInfo = new ProcessStartInfo(processPath) { UseShellExecute = false , CreateNoWindow = false }; _embeddedProcess = Process.Start(startInfo); // 使用超时机制等待窗口句柄创建，避免无限等待 _embeddedProcess.WaitForInputIdle( 3000 ); // 设置等待主窗口句柄的超时时间 DateTime timeout = DateTime.Now.AddSeconds( 5 ); while (_embeddedProcess.MainWindowHandle == IntPtr.Zero) { if (DateTime.Now > timeout) { throw new TimeoutException( "无法获取进程主窗口句柄" ); } Application.DoEvents(); // 保持UI响应 System.Threading.Thread.Sleep( 100 ); } // 设置父窗口 WindowsAPI.SetParent(_embeddedProcess.MainWindowHandle, _parentControl.Handle); // 设置窗口样式 int style = WindowsAPI.GetWindowLong(_embeddedProcess.MainWindowHandle, GWL_STYLE); style |= WS_CHILD | WS_VISIBLE; // 添加WS_VISIBLE确保窗口可见 WindowsAPI.SetWindowLong(_embeddedProcess.MainWindowHandle, GWL_STYLE, style); // 调整窗口位置和大小 WindowsAPI.MoveWindow( _embeddedProcess.MainWindowHandle, 0 , 0 , _parentControl.ClientSize.Width, _parentControl.ClientSize.Height, true ); // 确保父控件在尺寸变化时调整嵌入程序的大小 _parentControl.SizeChanged += (sender, e) => { if (_embeddedProcess != null && !_embeddedProcess.HasExited) { WindowsAPI.MoveWindow( _embeddedProcess.MainWindowHandle, 0 , 0 , _parentControl.ClientSize.Width, _parentControl.ClientSize.Height, true ); } }; } catch (Exception ex) { MessageBox.Show($ "嵌入进程时出错: {ex.Message}" , "错误" , MessageBoxButtons.OK, MessageBoxIcon.Error); } } public void CloseEmbeddedProcess () { if (_embeddedProcess != null && !_embeddedProcess.HasExited) { try { _embeddedProcess.CloseMainWindow(); if (!_embeddedProcess.WaitForExit( 3000 )) { _embeddedProcess.Kill(); } } catch (Exception ex) { MessageBox.Show($ "关闭进程时出错: {ex.Message}" , "错误" , MessageBoxButtons.OK, MessageBoxIcon.Error); } finally { _embeddedProcess.Dispose(); _embeddedProcess = null; } } } } } 实际应用示例 嵌入记事本示例 public partial class NotePadForm : Form { private ExternalProcessManager _processManager; public NotePadForm () { InitializeComponent(); // 创建一个Panel用于容纳记事本 Panel notepadPanel = new Panel { Dock = DockStyle.Fill }; this .Controls.Add(notepadPanel); _processManager = new ExternalProcessManager(notepadPanel); } private void btnEmbedNotepad_Click (object sender, EventArgs e) { _processManager.EmbedProcess( "notepad.exe" ); } protected override void OnFormClosing (FormClosingEventArgs e) { _processManager.CloseEmbeddedProcess(); base.OnFormClosing(e); } }
嵌入计算器示例 public partial class CalculatorForm : Form { private ExternalProcessManager _processManager; private Panel _calcPanel; public CalculatorForm () { InitializeComponent(); // 创建计算器面板 _calcPanel = new Panel { Size = new Size( 300 , 400 ), Location = new Point( 10 , 10 ) }; this .Controls.Add(_calcPanel); _processManager = new ExternalProcessManager(_calcPanel); Button embedButton = new Button { Text = "嵌入计算器" , Location = new Point( 320 , 10 ) }; embedButton.Click += EmbedCalculator_Click; this .Controls.Add(embedButton); } private void EmbedCalculator_Click (object sender, EventArgs e) { _processManager.EmbedProcess( "calc.exe" ); } protected override void OnFormClosing (FormClosingEventArgs e) { _processManager.CloseEmbeddedProcess(); base.OnFormClosing(e); } } 常见问题解决 窗口无法正确嵌入
// 确保等待窗口句柄创建 while (process.MainWindowHandle == IntPtr.Zero) { System.Threading.Thread.Sleep( 100 ); process.Refresh(); } DPI缩放问题
protected override void OnLoad (EventArgs e) { base.OnLoad(e); if (Environment.OSVersion.Version.Major >= 6 ) { SetProcessDPIAware(); } } [DllImport( "user32.dll" )] private static extern bool SetProcessDPIAware () ; 窗口大小调整
protected override void OnResize (EventArgs e) { base.OnResize(e); if (_embeddedProcess != null && !_embeddedProcess.HasExited) { WindowsAPI.MoveWindow(_embeddedProcess.MainWindowHandle, 0 , 0 , _parentControl.Width, _parentControl.Height, true ); } } 总结 通过本文的详细介绍和示例，你应该能够在C# WinForms应用程序中成功实现外部程序的嵌入和控制。记住要注意进程管理、窗口处理、性能优化和安全性等关键方面。合理使用这些技术可以帮助你创建更强大和灵活的应用程序。
